DIVA SLIM PELLET BOILER STOVE
5
EN - Rev. 1.0
Pellet loading panel
Left-hand inspection
compartment
(electronics and tank)
Combustion chamber
door
FRONT VIEW
LEFT-HAND INSPECTION COMPARTMENT
Right-hand inspection
compartment
(hydraulic circuit)
Ash tray door
Lower front inspection
compartment
(flue gas path and tray
cleaning)
TOUCH display
Tank inspection hatch
Pellet level
sensor
Gearmotor
Upper front
inspection
compartment
Flue gas path front
inspection plate
