klover ECOMPACT 290 - Technical Specifications

10
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
Technical specifications ECOMPACT 150
Heat input (nominal setting)
kW (Kcal/h)
15.7 (13,500)
Heat input (reduced setting)
kW (Kcal/h)
4.5 (3,850)
Nominal thermal output
kW (Kcal/h)
14.6 (12,550)
Reduced thermal power
kW (Kcal/h)
4.2 (3,600)
Efficiency delivered to water at nominal thermal power
%
92.6
Efficiency delivered to water at reduced thermal power
%
93.3
CO at 10% oxygen at nominal thermal power
%
0.010
CO at 10% oxygen at reduced thermal power
%
0.033
Maximum power uptake
Watt
430*
Power uptake during operation at nominal thermal power
Watt
63
Power uptake during operation at reduced thermal power
Watt
35
Power uptake in stand-by
Watt
2
Nominal voltage
V
230
Nominal frequency
Hz
50
Expansion vessel litres/preloading bar
10 / 1
Maximum operating/recommended pressure
bar
2.5 / 1.5
Water side resistance at Δt= 20 K
mbar
135
Flue outlet diameter
mm
100
Air intake pipe diameter
mm
40
Minimum chimney draught at nominal thermal power
Pa
10.5
Minimum chimney draught at reduced power
Pa
6.7
Combustion gas mass at nominal thermal power
g/s
10.3
Combustion gas mass at reduced power
g/s
4.5
Pellet tank capacity
lt (kg)
92 (55)
Pellet tank filling opening dimensions
mm
330 x 260
Average exhaust flue gas temperature at nominal thermal power
°C
107.3
Average exhaust flue gas temperature at reduced power
°C
85.2
Boiler unit capacity
litres
42
Width
mm
1120
Height
mm
1150
Depth
mm
500
Minimum safety distance from flammable materials (side/rear)
mm
200 / 200
Weight
Kg
300
Boiler class as per EN303-5:2012
5
* Power consumption only during the ignition cycle.
The appliance's heat output may vary depending on the type of pellets used.
