klover ECOMPACT 290 - Parameter Tables Ecompact 290

44
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
Parameter tables ECOMPACT 290
Parameters “VARIOUS CALIBRATIONS” - Mod. ECO290 (i05_220318)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
o0
Pr38
M08 – 4 – 01
Re-ignition block
RE-IGNIT BLOCK
Minutes
0 – 10
6
Pr39
M08 – 4 – 02
Flue gas extractor switch-off time
MIN-EXT OFF
Minutes
0 – 20
10
Pr40
M08 – 4 – 03
Pre-loading time in ignition
IGNIT- PRE-LOAD
Seconds
0 – 255
140
Pr41
M08 – 4 – 04
Stand-by time after pre-loading
AFTER-PRE STAND-BY
Seconds
0 – 255
160
Pr42
M08 – 4 – 05
Extractor speed in pre-loading phase
FLUE GAS-EXT
PRELOAD
RPM
350 – 2800
2100
Pr43
M08 – 4 – 06
ON/OFF temperature hysteresis on “SET H2O”
DELTA ON OFF AUTO
°C
0.0 – 20.0
5.0
Pr44
M08 – 4 – 07
Delay at economy operation mode switch-off (timer after reaching “SET
H2O”)
DELAY-OFF AUTO
Minutes
2 – 120
20
Pr45
M08 – 4 – 08
Power change delay
POWER CHANGE
Seconds
0 – 60
20
Pr46
M08 – 4 – 09
ON/OFF Temperature hysteresis on “SET ROOM”
DELTA ON AUTO
°C
0.0 – 15.0
2.0
Pr47
M08 – 4 – 10
Keypad lock enable
KEY LOCK-EN
On – off
On – off
Off
Pr48
M08 – 4 – 11
Time after which an alarm is triggered in the event of a blackout
BLACKOUT ALARM
Seconds
0 – 60
30
Pr49
M08 – 4 – 12
Pellet level sensor enable
PELLET RESERVE
On – off
On – off
On
Pr50
M08 – 4 – 13
Pump start threshold and power modulation for overheating safety
PUMP SAFETY
°C
60 – 90
80
Pr51
M08 – 4 – 14
3-way switching and re-ignition delta on “SET BOILER” and “SET
BUFFER”
DELTA PUF-BOI
°C
0 – 15
5
Pr52
M08 – 4 – 15
Preheating time
PREHEATING TIME
Seconds
0 – 480
0
Pr53
M08 – 4 – 16
Extractor speed in preheating phase
PREHEAT-F.GAS-
SPEED
RPM
500 – 2800
2800
Pr54
M08 – 4 – 17
Time after which the “NO PELLET” alarm is triggered if “PELLET
RESERVE”
RESERVE ALARM
Minutes
1 – 180
40
Pr55
M08 – 4 – 18
ON time for turbulator cleaning gear motor
TURBOLAT DURATION
Seconds
0 – 600”
120
Pr56
M08 – 4 – 19
ON time for brazier cleaning gear motor (NOT USED)
CLEANING TIME
Seconds
0 – 120”
0
Pr57
M08 – 4 – 20
Time from switching off after which the brazier cleaning takes place (NOT
USED)
CLEANER DELAY
Minutes
1 – 15’
1
Pr58
M08 – 4 – 21
Time from switching ON after which the brazier cleaning takes place (NOT
USED)
CLEANER STAND-BY
Hours
1 – 24
24
Pr59
M08 – 4 – 22
Pump activation threshold and switching 3-way valve in DHW OUTPUT
MODE (with Type 2 System)
PUMP THRESHOLD I2
°C
55 – 75
60
Parameters “VACUUM CALIBRATIONS” - Mod. ECO290 (i05_220318)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
o0
Pr133
M08 – A – 01
Enable automatic pellet loading vacuum
ENABLE VACUUM
On – off
On – Off
Off
Pr134
M08 – A – 02
Vacuum on time
VACUUM ACTIVE
Seconds
1 – 180
20
Pr135
M08 – A – 03
Vacuum rest time
VACUUM PAUSE
Seconds
5 – 60
10
Pr136
M08 – A – 04
Number of operating cycles
VACUUM CYCLES
Number
1 – 20
15
Pr137
M08 – A – 05
Enables a Vacuum operating test to be performed
VACUUM TEST
On – off
On – off
Off
Parameters “FACTORY CALIBRATIONS” - Mod. ECO290 (i05_220318)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
o0
Pr01
M08 – 6 – 01
Ignition cycle maximum time
IGNIT- MINUTES
Minutes
5 – 25
18
Pr02
M08 – 6 – 02
Start time
START MINUTES
Minutes
2 – 12
8
Pr03
M08 – 6 – 03
Time interval between the two brazier cleaning operations
BRAZIER CLEANING
Minutes
3 – 240
90
Pr04
M08 – 6 – 04
Screw feed gear motor ON time in ignition phase
IGNIT- SCREW FEED
Seconds
0.1 – 8.0
0.6
Pr05
M08 – 6 – 05
Screw feed gear motor ON time in start phase
SCREW FEED START
Seconds
0.1 – 8.0
0.8
Pr06
M08 – 6 – 06
Screw feed gear motor ON time in power 1 work phase
OUTPUT 1 SCREW
FEED
Seconds
0.1 – 8.0
2.4
Pr07
M08 – 6 – 07
Screw feed gear motor ON time in power 2 work phase
OUTPUT 2 SCREW
FEED
Seconds
0.1 – 8.0
3.6
Pr08
M08 – 6 – 08
Screw feed gear motor ON time in power 3 work phase
OUTPUT 3 SCREW
FEED
Seconds
0.1 – 8.0
4.6
