PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
PCB PARAMETERS
The parameters stored on the PCB are essential for the correct operation.
The following parameters are already stored during the testing of the appliance directly in the factory; these parameters
are the result of special tests using several types of pellets and must not be changed without the authorisation of Klover
srl so as not to impair the operation of the appliance.
The company shall not be held liable for any damage caused by the incorrect entry of parameters.
Parameter tables ECOMPACT 150
Parameters “VARIOUS CALIBRATIONS” - Mod. ECO150 (i05_220318)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
M0
Pr38
M08 – 4 – 01
Re-ignition block
RE-IGNIT BLOCK
Minutes
0 – 10
6
Pr39
M08 – 4 – 02
Flue gas extractor switch-off time
MIN-EXT OFF
Minutes
0 – 20
10
Pr40
M08 – 4 – 03
Pre-loading time in ignition
IGNIT- PRE-LOAD
Seconds
0 – 255
240
Pr41
M08 – 4 – 04
Stand-by time after pre-loading
AFTER-PRE STAND-BY
Seconds
0 – 255
180
Pr42
M08 – 4 – 05
Extractor speed in pre-loading phase
FLUE GAS-EXT
PRELOAD
RPM
350 – 2800
2200
Pr43
M08 – 4 – 06
ON/OFF temperature hysteresis on “SET H2O”
DELTA ON OFF AUTO
°C
0.0 – 20.0
5.0
Pr44
M08 – 4 – 07
Delay at economy operation mode switch-off (timer after reaching “SET
H2O”)
DELAY-OFF AUTO
Minutes
2 – 120
20
Pr45
M08 – 4 – 08
Power change delay
POWER CHANGE
Seconds
0 – 60
20
Pr46
M08 – 4 – 09
ON/OFF Temperature hysteresis on “SET ROOM”
DELTA ON AUTO
°C
0.0 – 15.0
2.0
Pr47
M08 – 4 – 10
Keypad lock enable
KEY LOCK-EN
On – off
On – off
Off
Pr48
M08 – 4 – 11
Time after which an alarm is triggered in the event of a blackout
BLACKOUT ALARM
Seconds
0 – 60
30
Pr49
M08 – 4 – 12
Pellet level sensor enable
PELLET RESERVE
On – off
On – off
On
Pr50
M08 – 4 – 13
Pump start threshold and power modulation for overheating safety
PUMP SAFETY
°C
60 – 90
80
Pr51
M08 – 4 – 14
3-way switching and re-ignition delta on “SET BOILER” and “SET
BUFFER”
DELTA PUF-BOI
°C
0 – 15
5
Pr52
M08 – 4 – 15
Preheating time
PREHEATING TIME
Seconds
0 – 480
0
Pr53
M08 – 4 – 16
Extractor speed in preheating phase
PREHEAT-F.GAS-
SPEED
RPM
500 – 2800
2800
Pr54
M08 – 4 – 17
Time after which the “NO PELLET” alarm is triggered if “PELLET
RESERVE”
RESERVE ALARM
Minutes
1 – 180
40
Pr55
M08 – 4 – 18
ON time for turbulator cleaning gear motor
TURBOLAT DURATION
Seconds
0 – 600”
120
Pr56
M08 – 4 – 19
ON time for brazier cleaning gear motor (NOT USED)
CLEANING TIME
Seconds
0 – 120”
0
Pr57
M08 – 4 – 20
Time from switching OFF after which the brazier cleaning takes place
(NOT USED)
CLEANER DELAY
Minutes
1 – 15’
1
Pr58
M08 – 4 – 21
Time from switching ON after which the brazier cleaning takes place (NOT
USED)
CLEANER STAND-BY
Hours
1 – 24
24
Pr59
M08 – 4 – 22
Pump activation threshold and switching 3-way valve in DHW OUTPUT
MODE (with Type 2 System)
PUMP THRESHOLD I2
°C
55 – 75
60
Parameters “VACUUM CALIBRATIONS” - Mod. ECO150 (i05_220318)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
M0
Pr133
M08 – A – 01
Enable automatic pellet loading vacuum
ENABLE VACUUM
On – off
On – Off
Off
Pr134
M08 – A – 02
Vacuum on time
VACUUM ACTIVE
Seconds
1 – 180
20
Pr135
M08 – A – 03
Vacuum rest time
VACUUM PAUSE
Seconds
5 – 60
10
Pr136
M08 – A – 04
Number of operating cycles
VACUUM CYCLES
Number
1 – 20
15
Pr137
M08 – A – 05
Enables a Vacuum operating test to be performed
VACUUM TEST
On – off
On – off
Off
Parameters “FACTORY CALIBRATIONS” - Mod. ECO150 (i05_220318)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
M0
Pr01
M08 – 6 – 01
Ignition cycle maximum time
IGNIT- MINUTES
Minutes
5 – 25
18
Pr02
M08 – 6 – 02
Start time
START MINUTES
Minutes
2 – 12
8
