klover SMART 120 - Page 12

12
ROOM
THERMOSTAT
CONNECTION
CLAMP
AIR INTAKE PIPE
FLUE
EXHAUST
RETURN
ATTACHM
ENT
DOMESTIC COLD
WATER INLET (ONLY ON
MOD. WITH SET-UP)
+ SYSTEM LOAD AND
BOILER BODY
DOMESTIC HOT
WATER OUTLET
(ONLY ON SET-UP
MOD.)
FLOW
CONNECTION
WITH CHECK
VALVE
