klover SMART 120 - Circuit Board Parameters; Various Calibration Parameters

55
CIRCUIT BOARD PARAMETERS
THE PARAMETERS STORED ON THE CIRCUIT BOARD ARE ESSENTIAL FOR THE PROPER
OPERATION OF THE CENTRAL HEATING COOKER.
THE PARAMETERS GIVEN BELOW HAVE ALREADY BEEN STORED DURING THE CENTRAL HEATING
COOKER TESTING PHASE DIRECTLY IN THE FACTORY.
THESE PARAMETERS ARE THE RESULT OF CAREFUL TESTS WITH VARIOUS TYPES OF
PELLETS, AND SHOULD NOT BE CHANGED WITHOUT THE PERMISSION OF KLOVER srl SO AS
NOT TO IMPAIR THE CENTRAL HEATING COOKER OPERATION.
THE MANUFACTURER DISCLAIMS ALL LIABILITY FOR ANY DAMAGE CAUSED BY IMPROPER
PARAMETER ENTRIES.
“Various calibrations” (Menu M – 9 – 4)
Parameter
Menu level
Description
Display writing
Measurement
Value field
Database o0
Pr38
M – 9 – 4 – 01
Re-ignition block
RE-IGNIT BLOCK
Minutes
0 – 10
6
Pr39
M – 9 – 4 – 02
Flue gas intake device switch-off time
MIN-INT OFF
Minutes
0 – 20
10
Pr40
M – 9 – 4 – 03
Ignition pre-load time
IGNIT- PRE-LOAD
Seconds
0 – 225
85
Pr41
M – 9 – 4 – 04
Stand-by time after pre-load
AFTER-PRE STAND-BY
Seconds
0 – 255
210
Pr42
M – 9 – 4 – 05
Intake device speed in pre-load phase
PRELOAD FLUE GAS-
INTAKE DEVICE
Revs/min
350 – 2800
2100
Pr43
M – 9 – 4 – 06
ON/OFF Temperature hysteresis on
“SET H2O” and “SET DHW”
DELTA ON OFF AUTO
°C
0 – 20
5
Pr44
M – 9 – 4 – 07
Delay at economy operation mode
switch-off (timer after reaching “SET
H2O”)
DELAY-OFF AUTO
Minutes
2 – 120
30
Pr45
M – 9 – 4 – 08
Power change delay
POWER CHANGE
Seconds
0 – 60
20
Pr46
M – 9 – 4 – 09
ON/OFF Temperature hysteresis on
“SET ROOM”
DELTA ON AUTO
°C
0 – 15
2
Pr47
M – 9 – 4 – 10
Keypad block enabling
KEYS BLOCK-EN
On – off
On – off
Off
Pr48
M – 9 – 4 – 11
Automatic re-ignition after black-out
BLACK OUT RE-
IGNITION
Seconds
0 – 60
30
Pr49
M – 9 – 4 – 12
Pellet level sensor enabling
PELLET RESERVE
On – off
On – off
On
Pr50
M – 9 – 4 – 13
Pump ignition for over-temperature
safety
PUMP SAFETY
°C
60 - 90
83
Pr51
M – 9 – 4 – 14
“SET OVEN” Temperature
SET OVEN
°C
70 - 80
75
