klover SMART 120 - Connection Data Sheet - Upper Flue

13
Connections data sheet (Model with upper flue gas outlet)
M = Ø ¾” F GAS SYSTEM FLOW
R = Ø ¾” M GAS SYSTEM RETURN
C = Ø 14 mm DOMESTIC HOT WATER OUTLET (on prepared models only)
F = Ø 14 mm DOMESTIC COLD WATER INLET
S = Ø 100 mm M FLUE OUTLET
A = Ø 50 mm AIR SUCTION DEVICE
955
250
70
350
295
235
65
170
320
150
115
90
M
R
F
C
A
S
1200
600
875
REAR
VIEW
