klover SMART 120 - Default Settings Overview

56
“Default settings” (Menu M – 9 – 6)
Parameter
Menu level
Description
Display writing
Measurement
Value field
Database o0
Pr01
M – 9 – 6 – 01
Ignition cycle maximum time
IGNIT- MINUTES
Minutes
5 – 25
25
Pr02
M – 9 – 6 – 02
Start time
START MINUTES
Minutes
2 – 12
5
Pr03
M – 9 – 6 – 03
Time interval between the two brazier
cleaning operations
BRAZIER CLEANING
Minutes
3 – 240
60
Pr04
M – 9 – 6 – 04
Screw feed motor reducer ON time in
ignition phase
IGNIT- SCREW FEED
Seconds
0.1 – 8.0
2,2
Pr05
M – 9 – 6 – 05
Screw feed motor reducer ON time in start
phase
START SCREW FEED
Seconds
0.1 – 8.0
2,0
Pr06
M – 9 – 6 – 06
Screw feed motor reducer ON time in
output 1 working mode
OUTPUT 1 SCREW
FEED
Seconds
0.1 – 8.0
1,8
Pr07
M – 9 – 6 – 07
Screw feed motor reducer ON time in
output 2 working mode
OUTPUT 2 SCREW
FEED
Seconds
0.1 – 8.0
2,8
Pr08
M – 9 – 6 – 08
Screw feed motor reducer ON time in
output 3 working mode – Oven output 1
OUTPUT 3 SCREW
FEED
Seconds
0.1 – 8.0
4,2
Pr09
M – 9 – 6 – 09
Screw feed motor reducer ON time in
output 4 working mode – Oven output 2
OUTPUT 4 SCREW
FEED
Seconds
0.1 – 8.0
5,4
Pr10
M – 9 – 6 – 10
Screw feed motor reducer ON time in
output 5 working mode – Oven output 3
OUTPUT 5 SCREW
FEED
Seconds
0.1 – 8.0
6,8
Pr11
M – 9 – 6 – 11
Alarm delay
ALARM DELAY
Seconds
20 – 90
30
Pr12
M – 9 – 6 – 12
Brazier cleaning duration
BRAZIER CLEANING
Seconds
0 – 120
40
Pr13
M – 9 – 6 – 13
Flue gas minimum temperature to
consider the boiler on
MINIMUM
THRESHOLD
°C
40 – 180
50
Pr14
M – 9 – 6 – 14
Flue gas maximum temperature
MAXIMUM
THRESHOLD
°C
110 – 250
250
Pr15
M – 9 – 6 – 15
Flue gas temperature threshold for the
exchanger ignition (NOT USED)
FAN THRESHOLD
°C
50 – 210
60
Pr16
M – 9 – 6 – 16
Flue gas intake device speed in ignition
phase
IGNIT FLUE GAS
SPEED
Revs/min
500 – 2800
2100
Pr17
M – 9 – 6 – 17
Flue gas intake device speed in start
phase
START FLUE GAS
SPEED
Revs/min
500 – 2800
2200
Pr18
M – 9 – 6 – 18
Flue gas intake speed in output 1 working
mode
P 1 FLUE GAS
SPEED
Revs/min
500 – 2800
1600
Pr19
M – 9 – 6 – 19
Flue gas intake speed in output 2 working
mode
P 2 FLUE GAS
SPEED
Revs/min
500 – 2800
1750
Pr20
M – 9 – 6 – 20
Flue gas intake speed in output 3 working
mode – Oven output 1
P 3 FLUE GAS
SPEED
Revs/min
500 – 2800
1900
Pr21
M – 9 – 6 – 21
Flue gas intake speed in output 4 working
mode – Oven output 2
P 4 FLUE GAS
SPEED
Revs/min
500 – 2800
2100
Pr22
M – 9 – 6 – 22
Flue gas intake speed in output 5 working
mode – Oven output 3
P 5 FLUE GAS
SPEED
Revs/min
500 – 2800
2250
Pr23
M – 9 – 6 – 23
Exchanger 1 motor speed in output 1
working mode (NOT USED)
AIR 1 SPEED
Volt
65 – 225
65
Pr24
M – 9 – 6 – 24
Exchanger 1 motor speed in output 2
working mode (NOT USED)
AIR 2 SPEED
Volt
65 – 225
65
Pr25
M – 9 – 6 – 25
Exchanger 1 motor speed in output 3
working mode (NOT USED)
AIR 3 SPEED
Volt
65 – 225
65
Pr26
M – 9 – 6 – 26
Exchanger 1 motor speed in output 4
working mode (NOT USED)
AIR 4 SPEED
Volt
65 – 225
65
Pr27
M – 9 – 6 – 27
Exchanger 1 motor speed in output 5
working mode (NOT USED)
AIR 5 SPEED
Volt
65 – 225
65
Pr28
M – 9 – 6 – 28
Flue gas intake device switch-off
threshold (in switch-off phase)
THRESHOLD OFF
°C
50 – 180
70
Pr29
M – 9 – 6 – 29
Flue gas intake device speed in brazier
cleaning phase
FLUE GAS-INTAKE
DEVICE CLEANING
Revs/min
500 – 2800
2800
Pr30
M – 9 – 6 – 30
Screw feed motor reducer ON time in
cleaning phase
CLEANING SCREW
FEED
Seconds
0.1 – 8.0
1,5
Pr31
M – 9 – 6 – 31
Flue gas intake device encoder enabling
(NOT USED)
ENCODER
On – off
On – off
On
Pr32
M – 9 – 6 – 32
Screw feed brake time
BRAKE TIME
Seconds
0 – 0.5
0,2
Pr33
M – 9 – 6 – 33
Pump activation threshold
PUMP THRESHOLD
°C
20 – 70
55
Pr34
M – 9 – 6 – 34
Water pressure switch enabling (NOT
USED)
WATER
PRESSURESW.
On – off
On – off
Off
Pr35
M – 9 – 6 – 35
Water pressure threshold (NOT USED)
PRESSURE
THRESHOLD
Bar
1.5 – 3.0
2,5
Pr36
M – 9 – 6 – 36
Screw feed motor reducer ON time in
DHW output working mode
DHW SCREW FEED
Seconds
0.1 – 8.0
6,8
Pr37
M – 9 – 6 – 37
Flue gas intake speed in DHW output
working mode
DHW FLUE GAS-
INTAKE DEVICE
Revs/min
500 – 2800
2250
