FURTHER SPECIFICATIONS TO BE CONSIDERED
The central heating cooker works with the combustion chamber in depression; it is essential that the
exhaust pipe is hermetically sealed.
We recommend using rigid stainless steel pipes, with sealing gaskets having a minimum diameter of
120 mm.
The pipes must be double-walled or adequately insulated with rock wool. The maximum
temperature of the pipe must not exceed 70 °C.
TO ENSURE PROPER FUME DISCHARGE PROVIDE FOR AN INITIAL VERTICAL TRACT OF AT
LEAST 1.5 METRES.
Each change of direction must be carried out with a T-shaped fitting and inspection cap.
Pipes must ensure sealing against smoke leakage via gaskets resistant to 250 °C.
Fix the pipes to the wall with suitable relevant metal collars to avoid any vibration.
WARNING: IT IS FORBIDDEN TO INSTALL DRAUGHT REGULATING VALVES (BUTTERFLY
VALVES).
There are two solutions for the connection to the flue:
SOLUTION 1 – REAR FLUE GAS OUTLET
