43
List of Display Messages
The following list shows messages that may appear on the main screen
of the Smartline Pump 1000 and the pages of this manual on which they
are described.
SYSTEMTEST OK 9
Conflict with existing programs 13
Start Time Is Fixed 22
Delete this line? Confirm by cursor 33
Error signal was detected 33
List of Error Codes
Table 6 Error codes in GLP Menu
Error Code Meaning
5 Motor failure
9 ERROR IN signal detected
10 Switch off due to exceeding maximum current
12 Switch off due to exceeding maximum pressure
13 Switch off due to falling below minimum pressure
23 Motor blocked
33 Calibrating values re-initialized
34 Calibrating curve re-initialized
35 Combination of error codes 33 and 34
