46 Technical Data
Technical Data
Delivery system Double-piston pump with main and auxiliary
piston
Automatic piston
backflushing standard
Flow Rate range
10 ml pump head 0.001– 9.999 ml/min at external control
50 ml pump head 0.01 – 50 ml/min
Flow accuracy < 0.5%, at 1ml/min, 12 MPa
Flow precision < 0.1%, at 1ml/min, 12 MPa
Residual pulsation < 0.5% at 1ml/min methanol : water (8:2), 12
MPa,
System protection Soft start, P
min
und P
max
adjustable
Max. operating pressure, depending on pump head type:
10 ml 40 MPa
50 ml 15 MPa
Control RS 232 interface,
Remote connections (Stop, Flow, Pressure,
Error)
Display 2 X 24 digits
Gradients Expandable to high pressure gradient
system (HPG) with up to 4 eluents
with Smartline Manager 5000 expandable to
low pressure gradient system (LPG) with up
to 4 eluents
Power Supply 90-260 V, 47 – 63 Hz, 100 W
Dimensions 226 x 135 x 390 mm (W x H x D)
Weight 5.3 kg
6.4 kg with dynamic mixing chamber
