EVOLUTION Instruction Manual
Version: C (Manual 0901170) 10 2024-1218
9. Attach the five liter container shelf (if equipped) to right side of case
using screws provided.
10. If unit is equipped with spout attach it to the male connector on the
bottom of the case and secure with a wrench. Avoid over tightening.
11. Install chemical level sensor.
a. Five Liter
i. Remove plug from top of the case as shown
ii. Insert level sensor cable and suction tube through barb fitting and push through opening
in the top of the case. Secure barb fitting with lock nut provided and push outer tube over
barb as shown
iii. Connect level sensor wire harness (red/black wires) to wires marked level sensor (black
and purple) black to black, red to purple
