OpEraTiON
8 Status: 04.11.21
4.2 Cutting, stripping and pressing 8-pin at cables into
Western plug type RJ 45
Only use open plugs without strain relief for this tool. “Pass through” plugs
and closed plugs cannot be crimped with this tool.
4.2.1 Cutting and stripping 8-core at cables
8-core at cables can be cut and stripped in one work step with this tool.
» Insert the cable into the holder from the front.
R
e
l
e
a
s
e
8P
6P
97 51 10
KNIPEX
8P
1.
2.
Cutting and stripping the at cable in one step
» Press the pliers completely together to cut the cable.
» Pull the cable out of the tool to strip the insulation.
8P
6P
97 51 10
KNIPEX
3.
8P
Withdrawing the ribbon cable to strip the insulation
