KoamTac KDC280 - Technical Specifications

KDC280NA QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC280_20220614 p11
Product Specifications
Physical
Design
Companion Bluetooth Barcode Scanner
Size
1.6” x 3.2” x 0.7” (40 mm x 82 mm x 18 mm)
Weight
2.0 oz (58 g)
Functionality
Supporting OS
Android / iOS / Windows / Mac OS X
Keys
Scan Key, Up Key, Down Key
Buzzer
Yes
LED Indicator
1 Status LED (Red / Amber / Green)
USB Port
1 Type-C USB Port
Memory
RAM
SDRAM 256KB
ROM (Flash)
Program Flash 1MB / User Data Flash 5MB
Barcode Storage
250,000+ Barcodes (EAN-13)
Power
Battery (Standard)
650 mAh Lithium-ion
Charging Solution
USB Connector / Charging Cradle
Charging Time
3 Hours
Communication
Bluetooth
Bluetooth Low Energy V5.0, HID/SPP
Type-C USB
USB Flash Memory (Windows) – 5MB
USB HID
USB Serial (Android with OTG cable / Windows)
Barcode Reader
1D/2D Symbology
Yes
# of scans per charge
(1 sec interval)
KDC280L Laser: TBD
KDC280D CCD: TBD
KDC280C Imager: 14,000+
# of scans per charge
(10 sec interval)
KDC280 Laser: TBD
KDC280 CCD: TBD
KDC280 Imager: 5,500+
Scan Range (20mil Code39)
KDC280L Laser: 1.97" to 17.72" (50 mm to 450 mm)
KDC280D CCD: 1.97" to 17.72" (50 mm to 450 mm)
KDC280C Imager: 2.36" to 18.35" (60mm to 466mm)
Screen Reading
Laser: No, CCD/Imager: Yes
Postal Code / OCR Passport
Yes / MRZ (Only for KDC280C Imager)
Environment
Drop Spec / IP Rating
5 ft (1.5 m) / IP65
Operating Temp.
14 ˚F to 122 ˚F (-10 ˚C to 50 ˚C)
Storage Temp.
-4 ˚F to 140 ˚F (-20 ˚C to 60 ˚C)
Humidity Spec
5% ~ 95% (non-condensing)
Regulatory
Conformance
Laser Safety
IEC60825-1 (Class I) (KDC280 Laser Model)
LED Safety
IEC62471:2006 (KDC280 CCD Model)
Regulatory
CE, FCC, KC, J-MIC, VCCI, SRRC, RoHS Compliant
Accessories
Charging Cradle
Yes (1-slot / 4-slot)
Finger Trigger Glove / Ring
No
Protective Boot
Yes
