KOBE ISX2130SQB-2 User Manual (English)

Questions and Answers:

S
Sean AllenJul 27, 2025
Why is my KOBE Ventilation Hood not venting out correctly?
- E
  Elizabeth ColeJul 27, 2025
  If your KOBE Ventilation Hood isn't venting correctly, it could be due to several reasons. First, ensure the hood is installed within the recommended clearance of 26” to 30” above the cooktop (30” to 36” for island hoods). Insufficient make-up air in the house can also be a factor; try opening a window to improve performance. Check for any obstructions in the ductwork and remove them. Also, verify that the duct size matches the manufacturer's suggestion and that all pipe connections are properly sealed.
K
karlasmithAug 1, 2025
What to do if KOBE ISX2130SQB-2 Ventilation Hood motors and lights are not working after installation?
- L
  Lisa DavisAug 1, 2025
  If, after installation, the motors and lights on your KOBE Ventilation Hood aren't working, start by ensuring that the circuit breaker and the unit's power are turned ON. Use a voltage meter to verify the power supply. Next, check all wire connections to make sure they are secure and tight. Finally, the control switch might be defective, in which case it will need to be replaced.
M
Mr. Brent JohnsonAug 6, 2025
Why is the motor working but the lights are not on my KOBE ISX2130SQB-2?
- X
  xblackburnAug 6, 2025
  If the motor in your KOBE Ventilation Hood is working but the lights are not, the LED light(s) might be defective and need replacement. Also, check the light wiring(s) to ensure they are not loose, verifying continuity from the light transformer to the LED light housing(s). Check the power input and output on the light transformer; if needed, replace the light transformer. A defective control switch can also cause this issue, so consider replacing it as well.
T
Tracy MullenAug 11, 2025
How to fix a vibrating KOBE ISX2130SQB-2 Ventilation Hood?
- A
  Aaron AllenAug 11, 2025
  If your KOBE Ventilation Hood is vibrating, it could be due to a few reasons. First, ensure the blower system is secure by tightening the turbine impeller/squirrel cage and air chamber. If the squirrel cage is unbalanced, it should be replaced. Also, check the hood's installation and tighten the mounting bracket to ensure it is securely in place.
M
Misty MunozAug 16, 2025
What to do if lights work but motor doesn't on KOBE ISX2130SQB-2?
- S
  Sean ColeAug 16, 2025
  If the lights on your KOBE Ventilation Hood are working, but the motor(s) is not, the motor(s) itself may be defective and require replacement. Alternatively, the capacitor(s) could be defective and need replacing. Lastly, a defective control switch could also be the cause, so consider replacing it.
S
Sarah BushAug 21, 2025
Why is cold air coming into my home from KOBE Ventilation Hood?
- S
  stephanie31Aug 21, 2025
  If cold air is coming into your home through the KOBE Ventilation Hood, it's likely that the damper is either not properly installed or is missing. Check the damper installation. Installing the damper will help eliminate air backflow.

KOBE ISX2130SQB-2 Specifications

General

Brand	KOBE
Model	ISX2130SQB-2
Category	Ventilation Hood
Language	English

Summary

Important Safety and Pre-Installation Checks

Pre-Installation Checklist

Verify package contents, inspect for damage, and test unit before installation.

Problem Resolution Protocol

Steps for handling issues, including keeping packaging and contacting support.

Safety Precautions and Warnings

General Safety Guidelines

Rules for preventing fire, shock, injury, proper venting, and maintenance.

Grease Fire Safety and Response

Precautions during cooking and actions during a grease fire.

Gas Leak and Electrical Safety

Gas Leak Detection and Response

Procedures to follow when smelling gas to prevent hazards.

Electrical Hazard and Mercury Warning

Dangers of electrical shock and handling of fluorescent bulb mercury.

Package Contents and Components

Main Unit and Duct Cover Parts

Lists hood body, duct covers, and telescopic stack components.

Accessories and Hardware

Details vent adapters, duct pipes, screw packages, and extension bars.

Installation Guide

Pre-Installation Calculations

Guidance on calculating installation dimensions using Table 1 for clearance.

Island Installation Preparation

Steps and considerations for installing the hood on an island configuration.

Installation Steps and Ductwork

Ceiling Preparation and Framing

Instructions for marking, cutting, and framing the ceiling for installation.

Hood and Duct Cover Assembly

Steps for attaching the telescopic stack and duct covers to the hood unit.

Ductwork Installation

Connecting the vent pipe to the adapter and ensuring an airtight seal.

Electrical Wiring and Final Checks

Electrical Wiring and Grounding

Connecting the hood to power, emphasizing proper grounding and safety.

Final Checks and Testing

Removing protective film, installing accessories, and testing the unit's operation.

Operating Instructions

Control Panel Overview

Explanation of the 3-speed mechanical control panel functions.

Maintenance and Cleaning

Hood Surface Cleaning

Procedures for cleaning the stainless steel surface, avoiding abrasives.

Baffle Filter and Oil Tunnel Cleaning

Instructions for draining and washing baffle filters and oil tunnels.

Product Specifications

Model, Material, and Performance

Details on model, material, consumption, blower, exhaust, and sound levels.

Dimensions and Weight

Physical dimensions of the hood, duct cover, and weights.

Measurements and Diagrams

Hood and Duct Cover Dimensions

Visual representation of hood and duct cover measurements.

Duct Extension Measurements

Duct Extension Dimensions

Diagrams showing dimensions for models with the outer duct extension.

Parts List

Component Identification

Table listing parts with their descriptions, model/size, and part numbers.

Parts Assembly Diagram

Exploded view illustrating the assembly and identification of various parts.

Circuit Diagram

Electrical Wiring Schematic

Schematic showing wiring connections for the motor, controls, capacitor, and driver.

Troubleshooting Common Issues

Motor and Light Malfunctions

Solutions for issues with motors not working or lights not functioning.

Vibration and Airflow Problems

Troubleshooting steps for vibration and incorrect air venting.

Operational and Airflow Issues

Solutions for cold air entry and improper pipe sealing.

Warranty Information

Warranty Coverage and Limitations

Details on warranty coverage, duration, and transferability.

Warranty Exclusions and Conditions

Warranty Exclusions and Voiding Conditions

List of conditions that void the warranty and items not covered.

Warranty Registration

Fields to fill for date of purchase, model, and serial number for service.

Manufacturer Information and Disclaimer

Company Contact and Usage Notice

KOBE Range Hoods address, website, and disclaimer for overseas use.
