Kodak 104 User Manual

12
Spare Parts
* available in Spare Parts Kit - Small, Part No. 1F7975
n/a - not available
Pos. Part No. Description
50 n/a Air channel
51 1F7957 Dryer heating element 110 V, 900 W
53 1F7959 Dryer fan 115 V, 50/60 Hz
54 1F7960 Solenoid valve 115 V, 50/60 Hz
55 n/a Securing bracket
56 * Switch - film detection
58 n/a Bracket for micro-rotary-switch
59 1F7961 Film feed tray
n/a Film feed tray graphic arts
60 1F7962 Developer heating element 110 V, 400 W
61 1F7963 Heat exchanger
62 1F7964 Temperature safety switch mounted on heat exchanger
63 1F7966 Temperature sensor
64 n/a Plate for air channel
65 n/a Channel dryer heating
53
65
64
50
51
55
54
56
58
60
61
62
63
59
