THEORY GUIDE Power Distribution
10DEC05
TG4825-1
Page
106 of 120
POWER SUPPLY
The CR 825/850 SYSTEM operates correctly when connected to the power sources
described in the table below. These voltages can be obtained from a line-and-neutral or line-
to-line connection. For all voltages, only a single-phase power distribution system is
necessary.
The input power is changed at the TRANSFORMER T1 to an output voltage of 120 V AC. No
additional FILTERS, TRANSFORMERS, or other devices are necessary to provide correct
operating voltage. Also, no procedures are necessary to set up the TRANSFORMER or
POWER SUPPLY.
Voltage Tolerance Current Frequency
100 V AC +10% 10 A 50/60 Hz
115 V AC +10% 10 A 50/60 Hz
120 V AC +10%, -13% 10 A 50/60 Hz
127 V AC +10% 10 A 50/60 Hz
200 V AC +10% 5 A 50/60 Hz
208 V AC +10% 5 A 50/60 Hz
220 V AC +10% 5 A 50/60 Hz
230 V AC +10% 5 A 50/60 Hz
240 V AC +10% 5 A 50/60 Hz
To Next Page
