Kodak DirectView CR 850 Theory Guide

THEORY GUIDE Cassette Handling
10DEC05
TG4825-1
Page
52 of 120
Plate Handling
The Plate Handling components remove the
PLATE from the CASSETTE SHELL and
fasten it to the EXTRACTION BAR.
The EXTRACTION BAR holds the
PLATE during the scanning operation, then
inserts it back into the CASSETTE SHELL.
H194_5028CC
Down for Scanning
Pulling the SCREEN
to the EXTRACTION BAR
Fastening the PLATE
END STOP
SCREEN
H194_5028CCA
CASSETTE
BAR
PLATE
CASSETTE
EXTRACTION
EXTRACTION
BAR
HOOKS
HOOK YOKE LEVERS
