Kodak DirectView CR 850 Theory Guide

THEORY GUIDE Scan/Erase
10DEC05
TG4825-1
Page
71 of 120
EXTRACTION BAR
The EXTRACTION BAR holds the PLATE when it moves down during scanning and up after
erasing.
Note
The PLATE is not visible in the graphic.
H194_5015GC
EXTRACTION BAR
position-fixed
Erase position
position
Start of
scan position
position
Reference
Home position
H194_5015GCB
End of scan
