1 Printer Overview
This printer lets you print, copy, and scan pictures and documents. In addition, this
printer supports networking, letting you access the printer over a wireless (Wi-Fi) or
Ethernet network.
Components
1 Control panel 10 Output tray extender with paper stop
2 Power cord port 11 Output tray
3 USB port 12 Scanner glass
4 Ethernet port 13 Scanner lid
5 Duplexer/rear-access cleanout cover 14 Front paper-edge guides
6 Access door 15 Main paper tray
7 Printhead with ink cartridges installed 16 Paper tray extender
8 Front USB port 17 Left paper-edge guides
9 MS SD/HC MMC Card slot 18 Photo paper tray
