4-4 A-61771 March 2013
4. Insert the ink cartridge into the printer carrier as shown.
5. Press the green release tab and rotate the printer carrier to the “printing”
position.
6. Slide the printer carrier into the desired print position. See the section
entitled, “Changing print positions” later in this chapter.
7. Close the printer door.
NOTE: If the printer door will not close, verify that the printer carrier is in
the “printing” position.
