A-61771 March 2013 1-3
Scanner components
Front view
1 Output tray extender — can be opened to accommodate documents up
to 17 inches / 43.2 cm.
2 Gap release — turn the dial vertically to open the space between the
feed module and separation module for documents that require special
handling.
3 Input tray extender — pull this extender out to accommodate documents
longer than 11 inches / 27.94 cm.
4 Input tray— holds up to 250 documents (20 lb. / 75 g/m
2
) for scanning.
The input tray can be folded up when it is not in use.
5 Side guides — slide these guides in and out to accommodate the size of
the documents you are scanning.
6 Scroll buttons — press the Up or Down scroll buttons to scroll through
predefined functions or applications for scanning.
