Kohler 10CCE - Section 1. Service Views

TP-5977 7/98 Service Views 1
Section 1. Service Views
ADV-5687-D
1
2
3
4 5
6
7
8
9
10
12
13
8
11
1. Circuit breaker
2. Start/stop switch
3. Hourmeter
4. Fault lamp
5. Controller fuse
6. Controller
7. Exhaust outlet
8. Oil fill
9. Air cleaner
10. Cooling system fill
11. Radiator petcock
12. Oil drain
13. Oil filter
Figure 1-1. Service Views 10/12 kW 1-Phase
1
2
3
4
5
6
7
8
9
10
12
13
ADV-5755-D
8
11
1. Circuit breaker
2. Start/stop switch
3. Hourmeter
4. Fault Lamp
5. Controller fuse
6. Controller
7. Exhaust outlet
8. Oil fill
9. Air cleaner
10. Cooling system fill
11. Radiator petcock
12. Oil drain
13. Oil filter
Figure 1-2. Service Views 10/12 kW 3-Phase
