TP-6515 2/2116 Section 1 Specifications
ADV-9747-
1. Muffler
2. Oil check
3. Oil fill
4. Air cleaner
5. Fuses
6. RS-232 connector (for application program updates)
7. Controller user interface (see Figure 2-1)
8. Generator set master switch (RUN-OFF/RESET-AUTO)
9. Line circuit breaker
10. Field-connection terminal block location
11. Spark plug locations (both sides)
12. Oil drain hose
13. Oil drain valve
14. Oil filter
15. Exhaust
16. Equipment ground
17. Relay board location (optional)
18. Battery charger
19. DSAI lead location
20. Fuel block
21. Gas regulator assembly
22. Fuel solenoid valve
23. Nameplate location
24. Fuel inlet
25. Air intake
26. Engine starting battery location (battery purchased separately)
1 2 3
4
14
13
25
9
8
16
18
21
22
23
24
15
11
10
19
20
17
12
5
6
7
26
- A-- B-
- B-
0.006
A
- C-
+
25
Figure 1-2 Generator Set Components, 12kW
