TP-7092 11/22 23
1.8.5 Oil Pressure Sensor Boot Kit
The oil pressure sensor boot protects the oil pressure sensor and its connection from moisture and frost buildup that can cause
false low oil level faults. Install the oil pressure sensor boot in locations where the ambient temperature drops below 0°C (32°F).
See Figure 14 for illustrations of the installed kit. Follow the instructions provided with the kit to install the boot.
Figure 14 Oil Pressure Sensor Boot Location
1.8.6 Carburetor Heater
An optional carburetor heater is recommended for improved cold starting in locations where the ambient temperature drops
below 0°C (32°F). The carburetor heater prevents condensation and carburetor icing. The heater requires a continuous source
of AC power.
See the generator set Installation manual for more information.
Voltage
120 VAC
240 VAC
Thermostat ON
4 ± 3°C (40 ± 5°F)
Thermostat OFF
16 ± 3°C (60 ± 5°F)
Figure 15 Heater Specifications, 14 kW Models
Voltage
120 VAC
240 VAC
Thermostat ON
4 ± 4°C (40 ± 7°F)
Thermostat OFF
16 ± 3°C (60 ± 5°F)
Figure 16 Heater Specifications, 18 and 20 kW Models
Figure 17 Carburetor Heater with Thermostat and Power Connectors, 14 kW Models
Oil pressure sensor boot
14 kW Models
GM102176
18 and 20 kW Models
Thermostat
120 VAC plug
GM19463
240 VAC 3-pin Mate-N-Lock
connector
