4 — PROGRAMMABLE PARAMETERS
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 96
APPLICATION SETUP/VEHICLE — PERFORMANCE METRICS MENU
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Capture Speed 1
Capture_Speed_1
0x37C4 0x00
0 – 24000 rpm
0 – 24000
4500 The controller captures the time it takes the motor to go from 0
rpm to the programmed Capture Speed. This timer starts every
time the motor accelerates from zero speed.
The result is stored as “Time to Speed 1” in the Programmer
System Monitor » Vehicle menu.
Capture Speed 2
Capture_Speed_2
0x37C5 0x00
0 – 24000 rpm
0 – 24000
4500 This parameter allows a second capture speed to be dened, and
works identically to Capture Speed 1.The result is stored as “Time
to Speed 2” in the Programmer System Monitor » Vehicle menu.
Capture Distance 1
Capture_Distance_1
0x37C1 0x00
1 – 1320
1 – 1320
22 The controller captures the time it takes the vehicle to travel from
0 rpm to the programmed Capture Distance. The result is stored
as “Time to Dist 1” in the Programmer System Monitor » Vehicle
menu. This timer starts every time the vehicle accelerates from
zero speed.
Note: For accurate distance measuring, the Speed to RPM
parameter must be set correctly.
With the Metric Units parameter programmed Off, distance is in
units of feet. With Metric Units programmed On, distance is in
units of meters.
Capture Distance 2
Capture_Distance_2
0x37C2 0x00
1 – 1320
1 – 1320
100 This parameter allows a second capture distance to be
defined, and works identically to Capture Distance 1. The
result is stored as “Time to Dist 2” in the Programmer System
Monitor » Vehicle menu.
Capture Distance 3
Capture_Distance_3
0x37C3 0x00
1 – 1320
1 – 1320
150 This parameter allows a third capture distance to be defined,
and works identically to Capture Distance 1. The result is
stored as “Time to Dist 3” in the Programmer System Monitor
» Vehicle menu.
Vehicle Acceleration
Vehicle_Acceleration
0x37D9 0x00
0.000 – 10.000 g
0 – 10000
Read Only This is a calculated g-force value for the vehicle’s acceleration.
For an accurate measurement, correctly set the Speed to
RPM parameter.
Time to Speed 1
Time_to_Capture_Speed_1
0x37D3 0x00
0.00 – 128.00 s
0 – 32000
Read Only Time taken for the vehicle to go from zero rpm to the programmed
Capture Speed 1 during its most recent such acceleration.
Time to Speed 2
Time_to_Capture_Speed_2
0x37D4 0x00
0.00 – 128.00 s
0 – 32000
Read Only Time taken for the vehicle to go from zero rpm to the programmed
Capture Speed 2 during its most recent such acceleration.
Time Between Speeds
Time_Between_Capture_Speeds
0x37CF 0x00
0.00 – 128.00 s
0 – 32000
Read Only Time taken for the vehicle to go from programmed Capture
Speed 1 to programmed Capture Speed 2 during its most recent
such acceleration.
Time to Dist 1
Time_to_Capture_Distance_1
0x37D0 0x00
0.00 – 128.00 s
0 – 32000
Read Only Time taken for the vehicle to travel from zero rpm to the
programmed Capture Distance 1 during its most recent such trip.
For accurate distance measurements, the Speed to RPM
parameter must be set correctly.
Time to Dist 2
Time_to_Capture_Distance_2
0x37D1 0x00
0.00 – 128.00 s
0 – 32000
Read Only Time taken for the vehicle to travel from zero rpm to the
programmed Capture Distance 2 during its most recent such trip.
For accurate distance measurements, the Speed to RPM
parameter must be set correctly.
