4 — PROGRAMMABLE PARAMETERS
pg. 111
Return to TOC Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022
CONTROLLER SETUP — INPUTS MENU, cont’d
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Analog 6 menu
Parameters for Voltage with Supply selection
Analog 6 Type
Analog_Input_6_Type
0x3310 0x00
Voltage with Supply
(selection menu)
– The Analog 6 Type “Voltage with Supply” selection operates the
Analog 6 input as a raw voltage at the pin with an internal pull-up
supply voltage.
The pin’s output voltage is 10V (approx.) with a 3 mA current limit
(to the external load/device). Reference Table 10.
Use this selection for operating resistive devices such as
thermistors and photocells and reading the voltage in VCL
using the Monitor variable analog_input_volts_6 (0x3B33), then
processing the value in the VCL program.
Voltage
Analog_Input_Volts_6
0x3B33 0x00
–327.68 – 327.67V
–32768 – 32767
Read Only The analog voltage at the analog 6 input (Input 6).
Percent
Analog_Input_Percent_6
0x3B3E 0x00
0.0 – 100.0 %
0 – 1000
Read Only The percentage of the voltage at the analog 6 input pin is based
upon the High and Low settings, i.e., the percent of:
[(analog_input_volts_6) – (analog_input_6_low)] /
[(analog_input_6_high) – (analog_input_6_low)]
Low
Analog_Input_6_Low
0x32FD 0x00
0.0 – 11.0V
0 – 1100
0.0V The minimum input voltage before a fault is declared. When the
Analog 6 Type selection is Voltage with Supply, this set point
represents the 0% point for the normalized input.
Faults:
When the voltage falls below this parameter, it will trigger
the Analog_6_OUT_OF_RANGE fault (flash code 0xB6, CAN
Index 0x2625).
If assigning the Throttle to Analog 6, the resulting fault will become
the Throttle Input fault (flash code 0x42, CAN Index 0x2210) if
Throttle_Source = 1.
If assigning the Brake to Analog 6, the resulting fault will become
the Brake Input fault (Flash code 0x44) if Brake_Source = 6.
High
Analog_Input_6_High
0x32FE 0x00
0.0 – 11.0V
0 – 110
11.0V The maximum input voltage before a fault is declared. When
the Analog 6 Type selection is Voltage with Supply, this set point
represents the 100% point for the normalized input.
Faults:
When the voltage rises above this parameter, it will trigger
the Analog_6_OUT_OF_RANGE fault (flash code 0xB6, Can
Index 0x2625).
If assigning the Throttle to Analog 6, the resulting fault will become
the Throttle Input fault (flash code 0x42, CAN Index 0x2210) if
Throttle_Source = 1.
If assigning the Brake to Analog 6, the resulting fault will become
the Brake Input fault (Flash code 0x44) if Brake_Source = 6.
Fault Tolerance
Analog_Input_6_Fault_Tolerance
0x331F 0x00
0.0 – 11.0V
0 – 1100
0.0V Species the voltage threshold above the congured high limit
or below the low limit, exceeding this results in an analog out of
range fault.
For example, if High = 9.6V, Low = 1V and Tolerance = 0.2V, an
input voltage between 1V to 9.6V is mapped to 0–100%.
Voltages above 9.8V (9.6 + 0.2) or below 0.8V (1V – 0.2V) trigger
the fault.
Analog 7 menu
Voltage
Analog_Input_Volts_7
0x3B34 0x00
–327.68 – 327.67V
–32768 – 32767
Read Only Voltage at analog 7 input (Input 7).
