Kohler Curtis F Series User Manual

4 — PROGRAMMABLE PARAMETERS
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 112
CONTROLLER SETUP — INPUTS MENU, cont’d
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Percent
Analog_Input_Percent_7
0x3B3F 0x00
0.0 – 100.0 %
0 – 1000
Read Only Voltage on a 0-100 percentage basis.
The percentage of the voltage at the input pin is based upon the
High and Low settings, i.e., the percent of:
[(analog_input_volts_7) – (analog_input_7_low)] /
[(analog_input_7_high) – (analog_input_7_low)]
Low
Analog_Input_7_Low
0x32FF 0x00
0.0 – 30.0V
0 – 3000
0.0V The minimum input voltage before a fault is declared.
This voltage represents the 0% point for the normalized inputs.
High
Analog_Input_7_High
0x3300 0x00
0.0 – 30.0V
0 – 3000
30.0V The maximum input voltage before a fault is declared.
This voltage is the 100% point for the normalized inputs.
Fault Tolerance
Analog_Input_7_Fault_Tolerance
0x334C 0x00
0.0 – 11.0V
0 – 1100
0.0V Species the voltage threshold above the congured high limit
or below the low limit, exceeding this results in an analog out of
range fault.
For example, if High = 9.6V, Low = 1V and Tolerance = 0.2V, an
input voltage between 1V to 9.6V is mapped to 0–100%.
Voltages above 9.8V (9.6 + 0.2) or below 0.8V (1V – 0.2V) trigger
the fault.
Analog 8 menu
Voltage
Analog_Input_Volts_8
0x3B35 0x00
–327.68 – 327.67V
–32768 – 32767
Read Only Voltage at analog 8 input (Input 8).
Percent
Analog_Input_Percent_8
0x32E4 0x00
0.0 – 100.0 %
0 – 1000
Read Only Voltage on a 0-100 percentage basis.
The percentage of the voltage at the input pin is based upon the
High and Low settings, i.e., the percent of:
[(analog_input_volts_8) – (analog_input_8_low)] /
[(analog_input_8_high) – (analog_input_8_low)]
Low
Analog_Input_8_Low
0x3307 0x00
0.0 – 30.0V
0 – 3000
0.0V The minimum input voltage before a fault is declared.
This voltage represents the 0% point for the normalized inputs.
High
Analog_Input_8_High
0x3308 0x00
0.0 – 30.0V
0 – 3000
30.0V The maximum input voltage before a fault is declared.
This voltage is the 100% point for the normalized inputs.
Fault Tolerance
Analog_Input_8_Fault_Tolerance
0x3377 0x00
0.0 – 11.0V
0 – 1100
0.0V Species the voltage threshold above the congured high limit
or below the low limit, exceeding this results in an analog out of
range fault.
For example, if High = 9.6V, Low = 1V and Tolerance = 0.2V, an
input voltage between 1V to 9.6V is mapped to 0–100%.
Voltages above 9.8V (9.6 + 0.2) or below 0.8V (1V – 0.2V) trigger
the fault.
Analog 9 menu
Voltage
analog_input_volts_9
0x3B36 0x00
–327.68 – 327.67V
–32768 – 32767
Read Only Voltage at the analog 9 input (Input 9).
Percent
Analog_Input_Percent_9
0x3B40 0x00
0.0 – 100.0 %
0 – 1000
Read Only Voltage on a 0-100 percentage basis.
The percentage of the voltage at the input pin is based upon the
High and Low settings. i.e., the % of:
[(analog_input_volts_9) – (analog_input_9_low)] /
[(analog_input_9_high) – (analog_input_9_low)]
