4 — PROGRAMMABLE PARAMETERS
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 136
Treat these parameters as READ ONLY commissioning RESULTS. The values are generated
(automatically) during ACIM commissioning. After successfully commissioning the ACIM motor,
an OEM may copy these values to another matching controller/system to duplicate the motor
performance in another vehicle. Copy all values exactly as commissioned.
Contact Curtis before making any changes, or if there are any questions.
NOTICE
MOTOR SETUP/INDUCTION MOTOR (ACIM) — CURRENT REGULATOR MENU
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Tuning Voltage
Tuning_Nominal_Pack_Volts
0x366B 0x00
Controller model basis
Auto generated by the
commissioning process
RESULTS
READ ONLY
The voltage when the current regulator was tuned. Used to scale
gains AND base speed. Base speed MUST be tuned at the same
voltage as the current regulator.
Kp d Axis Current
Kp_1_Current
0x3667 0x00
Controller model basis
Auto generated by the
commissioning process
RESULTS
READ ONLY
The current regulator proportional (Kp) gain for one axis.
Ki d Axis Current
Ki_1_Current
0x3666 0x00
Controller model basis
Auto generated by the
commissioning process
RESULTS
READ ONLY
The current regulator integral (Ki) gain for one axis.
Kp q Axis Current
Kp_2_Current
0x306A 0x00
Controller model basis
Auto generated by the
commissioning process
RESULTS
READ ONLY
The current regulator proportional (Kp) gain for one axis.
Ki q Axis Current
Ki_2_Current
0x306B 0x00
Controller model basis
Auto generated by the
commissioning process
RESULTS
READ ONLY
The current regulator integral (Ki) gain for one axis.
MOTOR SETUP — MOTOR SETUP STATUS MENU
Treat these parameters as read only, as outputs to the motor commissioning. To protect the controller, change them
only when authorized.
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Current Regulator Setup
Current_Regulator_Setup
0x326B 0x00
Off - On
0 – 1
Off
Read Only
A ag indicating that the current regulator test has been run.
Slip Gain Setup
Slip_Gain_Setup
0x326C 0x00
Off - On
0 – 1
Off
Read Only
A ag indicating that the slip gain test has been run.
Base Speed Setup
Base_Speed_Setup
0x326D 0x00
Off - On
0 – 1
Off
Read Only
A ag indicating that the base speed test has been run.
Automated Test Run
Automated_Test_Setup
0x326E 0x00
Off - On
0 – 1
Off
Read Only
A ag indicating that the motor specic automated test has
been run.
