7 — DIAGNOSTICS AND TROUBLESHOOTING
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 220
Table 24 Fault Code Troubleshooting Chart, cont’d
FLASH
CODE
FAULT NAME
(Curtis Integrated Toolkit™)
POSSIBLE CAUSES SET/CLEAR CONDITIONS FAULT ACTIONS
3-9
0x39
Main Contactor Did Not Close
Main_Contactor_Did_Not_Close
0x2221
Fault Type(s):
1 = Main did not close
when commanded.
2 = Main disconnected
during operation.
3 = Battery disconnected with
main enable off.
Type 1:
1. Main contactor did not close.
2. Main contactor tips are oxidized,
burned, or not making good contact.
3. An external load on the capacitor
bank (B+ connection terminal) is
preventing the capacitor bank
from charging.
4. Blown B+ fuse.
5. Main Contactor
parameters mistuned;
• Main Pull-in Voltage,
• Main Holding Voltage.
Type 2:
1. Main contactor opened
during operation (while
commanded closed).
2. Driver wiring to contactor’s coil
(e.g., pin wiring) removed
during operation.
3. Contactor/coil defective.
Type 3:
Battery not connected to B+
when main enable is off and
interlock applied.
Set: With the main contactor
commanded closed, the
capacitor bank voltage (B+
connection terminal) did not
charge to B+.
Clear: Reset Controller.
ShutdownVehicle:
ShutdownMotor
ShutdownMainContactor
ShutdownEMBrake
ShutdownThrottle
FullBrake
ShutdownPump
Dual Drive
Same, both motors
3-10
0x3A
Motor Setup Needed
Motor_Setup_Needed
0x2103
Fault Type(s):
Hex #
Bit1 – 4
Binary 0000 => bits 4 3 2 1
Motor setup is required.
Please refer to fault type.
Bit1: The current regulator needs to
be congured.
Bit2: The slip gain test needs to be run.
Bit3: The base speed test needs to
be run.
Bit4: The automated test needs to be
run (full motor commissioning).
Set: Default for both ACIM and
PMAC motors.
Clear: Run the appropriate motor
commissioning sequences.
Fault Action:
None.
Yet, the motor will not
operate until the motor
conguration and/or
commissioning tests are
complete.
4-2
0x42
Throttle Input
Throttle_Input
0x2210
Fault Type(s): *
1 = Outside the Low or
High parameter.
Throttle voltage exceeded
the Analog Low or Analog
High parameters for the
analog input dened for the
throttle input.
2 = Input 1 fault diagnostics may
be either out of range if it is
congured as a voltage input,
or may include potentiometer
faults if congured as a 2/3-
wire pot.
* based upon the associated
Analog Input faults.
1. Throttle voltage exceeded the
Analog Low or Analog High
parameters for the analog input
dened for the throttle input.
2. See Programmer » Controller
Setup » Inputs » Analog 1 Type.
3. See Programmer » Controller
Setup » Inputs » Congure.
Set: Throttle voltage exceeded
the Analog Low or Analog High
parameters for the analog input
dened for the throttle input.
Clear: Bring throttle input
voltage within the Min and Max
thresholds. Reset Controller.
ShutdownThrottle
Dual Drive
This Motor:
ShutdownThrottle
Other Motor:
No Action
