7 — DIAGNOSTICS AND TROUBLESHOOTING
pg. 221
Return to TOC Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022
Table 24 Fault Code Troubleshooting Chart, cont’d
FLASH
CODE
FAULT NAME
(Curtis Integrated Toolkit™)
POSSIBLE CAUSES SET/CLEAR CONDITIONS FAULT ACTIONS
4-4
0x44
Brake Input
Brake_Input
0x2310
Fault Type(s): 1*
*Triggered by the respective fault
diagnostic associated with the
brake input source (assigned
analogX input).
Set: See Throttle Input.
Note: An Input 1 fault
diagnostics may be out
of range if it is congured
as a voltage input or may
include potentiometer faults if
congured as a 2/3-wire pot.
Clear: Bring Brake Input
voltage within the Min and Max
thresholds. Reset Controller.
FullBrake
Dual Drive
Same, both motors.
Any additional fault action
that is programmed in
VCL (see AnalogX).
4-6
0x46
NV Memory Failure
NV_Memory_Failure
0x2830
Fault Type(s):
1 = Invalid checksum.
2 = NV write failed.
3 = NV read failed.
4 = NV write did not complete
during power down.
1. Failure to read or write to
nonvolatile (NV) memory.
2. Internal controller fault.
Set: Controller operating
system tried to read or write to
EEPROM memory and failed.
Clear: Download the correct
software and matching
parameter default settings
into the controller and
Reset Controller.
ShutdownAll:
ShutdownMotor
ShutdownMainContactor
ShutdownEMBrake
ShutdownThrottle
ShutdownInterlock
ShutdownDriver1
ShutdownDriver2
ShutdownDriver3
ShutdownDriver4
ShutdownDriver5
ShutdownDriver6
ShutdownDriver7
ShutdownPD
FullBrake
ShutdownPump
ShutdownCoilSupply
ShutdownVehicle
ShutdownLower
ShutdownLift
Dual Drive
Same, both motors
4-7
0x47
HPD Sequencing
Hpd_Sequencing
0x2211
Fault Type(s):
Type 1 through 9 - HPD
depends on HPD_SRO_Type
Type 10 - Interlock Anti-
Tiedown
1. Incorrect sequence in application
of Keyswitch, Interlock, Direction,
or Throttle.
2. Faulty wiring, crimps, or switches at
KSI, Interlock, Direction, or Throttle.
3. Moisture in above-noted digital
input switches causing invalid (real)
On/Off state.
4. Verify input switch status. See
Programmer » System Monitor
menu » Hardware Inputs »
Switch Status.
5. Verify Throttle. See Programmer »
System Monitor menu » Hardware
Inputs » Throttle Command.
Set: HPD (High Pedal Disable)
or SRO (Static Return to Off)
sequencing fault caused by
incorrect sequence of KSI,
interlock, direction, and
throttle inputs.
Clear: Reapply inputs in correct
sequence.
ShutdownThrottle
Dual Drive
Same, both motors
4-7
0x47
EMER Rev HPD
Emer_Rev_Hpd
0x2331
Fault Type(s): 1
Emergency Reverse operation has
concluded, but the throttle, forward
and reverse, and interlock inputs
have not been returned to neutral.
Set: At the conclusion of
Emergency Reverse, the fault
was set because various inputs
were not returned to neutral.
Clear: If EMR_Interlock = On,
clear the interlock, throttle, and
direction inputs.
If EMR_Interlock = Off, clear
the throttle and direction inputs.
ShutdownThrottle
ShutdownEMBrake
Dual Drive
Same, both motors
