7 — DIAGNOSTICS AND TROUBLESHOOTING
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 240
Table 24 Fault Code Troubleshooting Chart, cont’d
FLASH
CODE
FAULT NAME
(Curtis Integrated Toolkit™)
POSSIBLE CAUSES SET/CLEAR CONDITIONS FAULT ACTIONS
12-11
0xCB
Primary State Error
Primary_State_Error
0x2113
Fault Type(s):
These are internal issues
either occurring during startup,
parameter initialization,
secondary micro update or
other runtime issues.
1 = PRIMARY_DEVICE_
STARTUP = 0,
2 = PRIMARY_WAIT_KSI_
STABLE,
3 = PRIMARY_DEVICE_
STARTUP_VALID,
4 = PRIMARY_INITIALIZE_
PARAMETERS,
5 = PRIMARY_WAIT_FOR_
FIRST_SIGNALS,
6 = PRIMARY_WAIT_FOR_
SUPERVISOR,
7 = PRIMARY_RESTORE_
PARAMETER_FAIL,
8 = PRIMARY_SUPERVISOR_
FIRST_SIGNALS_ERROR,
9 = PRIMARY_SUPERVISOR_
STARTUP_ERROR,
10 = PRIMARY_STARTUP_
TIMER_FAILURE,
11 = PRIMARY_WAIT_CAN_
HANDSHAKING_DONE,
12 = PRIMARY_RUNNING.
If the fault persists, Contact Curtis. Set: Internal error with
the controller. Kindly reset
controller.
Clear: Reset controller.
NO_ACTION
(controller is not operable)
Dual Drive
Same, both motors
12-12
0xCC
PWM Input 29 Out of Range
PWM_Input_29_Out_of_Range
0x210D
Fault Type(s):
1 = The input is disconnected.
2 = The measured input
frequency is below the
(PWM_Input_29_Low_
Frequency) – (PWM_
Input_29_Frequency_
Fault_Tolerance).
3 = The measured input
frequency is above the
(PWM_Input_29_High_
Frequency) + (PWM_
Input_29_Frequency_
Fault_Tolerance).
4 = The measured duty cycle
is below set limits, (PWM_
Input_29_Low_Duty_Cycle)
– (PWM_Input_29_Duty_
Cycle_Fault_Tolerance).
5 = The measured duty cycle
is above set limits, (PWM_
Input_29_High_Duty_Cycle)
+ (PWM_Input_29_Duty_
Cycle_Fault_Tolerance).
1. This fault diagnostic execution
cycles every 4msec. The input
is considered disconnected if no
PWM signal occurs for 16msec or
the measurements are not updated
every 16msec.
2. Mistuned parameters.
3. Faulty wiring.
Set: The input frequency and/or
duty-cycle on Input 29 exceeds
the congured limits set by
PWM_Input_29_x_Duty_Cycle
and PWM_Input_29_x_
Frequency, where x = {Low,
High}.
Clear: Reset Controller.
Fault Action:
None, unless a fault action
is programmed in VCL.
Dual Drive
Same, both motors
