3. Mount the Bracket
NOTICE: The bracket must be installed vertically.
NOTE: Allow adequate clearance for servicing.
NOTE: If using the optional AC adapter (not supplied) consider the
distance to the nearest electrical outlet when positioning the bracket
within the specified range.
Locate the bracket within 10″ (254 mm) from the faucet centerline.
The bottom of the bracket should also be between 8″ (203 mm)
and 13″ (330 mm) above the cabinet floor.
Secure the bracket with the provided mounting screws. If
installing on drywall, use appropriate anchors (not supplied).
Bracket
10"
(254 mm)
8"
(203 mm)
13"
(330 mm)
Kohler Co. 7 1281441-2-C
