4. Install the Batteries
Disconnect the green connector from the valve box.
Slide the battery holder off the valve box.
Press the tabs to remove the cover from the battery holder.
IMPORTANT! Do not use rechargeable or lithium-ion batteries.
Insert six AA batteries into the battery holder.
Reinstall the cover on the battery holder with the flat part of the
green connector facing the front of the holder.
Slide the battery holder back onto the valve box.
IMPORTANT! Do not reconnect the green connector until
instructed to do so.
Valve Box
Battery
Green
Connector
Battery
Holder
Cover
Tab
1281441-2-C 8 Kohler Co.
