5. Install the Valve Box
IMPORTANT! Risk of restricted waterflow. The outlet hose must
not be taut or kinked when installed.
NOTICE: Handtighten the outlet hose connector. Do not use a
pliers or a wrench.
Thread the outlet hose onto the valve inlet.
Slide the valve box into the mounted bracket.
Tighten the locking screw to secure the valve box to the bracket.
Connect the spray hose to the valve box outlet. It will click into
place when the connection is secure.
Locking
Screw
Outlet
Hose
Spray Hose
Kohler Co. 9 1281441-2-C
