Kohler KD62V12 Service And Repair Manual

Repair Service and Repair Manual
Fuel system
Fig. 129: High pressure pipes
Reference
Key Screw specifications
Lubricant *
Reuse**
Torque Angle (°)
Step
± 5%
Step
± 5°
1 - - O Yes 1 26 Nm
19 ft-lb
- -
2 189 Nm
139 ft-lb
2 - - O Yes 1 26 Nm
19 ft-lb
- -
2 150 Nm
111 ft-lb
Tab. 27: Tightening specifications table
*Lubricants:
MG = Molykote G-n-plus
MW = Castrol Optimol paste white T
MH = Molykote HSC
O = Engine oil
XX = Loctite 243
YY = Loctite 577
**Refer to screws reuse rules. (For more information see: 5.3.2 Screws pre-tightening, reuse and
marking, page 264.)
116
© 2021 by Kohler Co. All rights reserved.
KD62V12 33525088601_7_1 EN_US
2021-07
