Service and Repair Manual Repair
Fuel system
Fig. 143: Connecting electrical contacts
u Connect electrical cables on the corresponding solenoid connector.
u Tighten to torque.
Specific values
Not applicable.
Tightening specifications
q Put all parts in place and tighten by hand before following the sequence.
Information
Refer to screws reuse rules. (For more information see: 5.3.2 Screws pre-tightening, reuse and
marking, page 264.)
Fig. 144: Injector
KD62V12 33525088601_7_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
125
