Service and Repair Manual Contents
3.5.1 Power unit
97
3.5.2 Torsional vibration damper removal and installation - SL2-1340
99
3.6 Fuel system
106
3.6.1 Fuel return and venting pipes removal and installation
106
3.6.2 High pressure pipes removal and installation
109
3.6.3 Fuel supply pipes removal and installation
117
3.6.4 Injector removal and installation (SL 205)
118
3.6.5 Fuel filters removal and installation
127
3.6.6 Leakage fuel block removal and installation
129
3.6.7 Fuel pump HP and LP removal and installation (SL 250)
130
3.6.8 Gearbox - Fuel pump removal and installation
135
3.7 Charge air system
139
3.7.1 Air intake line removal and installation
139
3.7.2 Charge air line removal and installation
140
3.7.3 Charge air cooler removal and installation (SL 220)
149
3.8 Exhaust gas system
154
3.8.1 Admission pipes to turbocharger removal and installation
154
3.8.2 Exhaust pipes to turbocharger removal and installation
156
3.8.3 Turbocharger removal and installation (SL 233)
165
3.8.4 Oil supply – turbocharger removal and installation
170
3.8.5 Turbocharger brackets removal and installation
175
3.8.6 Exhaust pipes and compensators (SL 214)
180
3.9 Lubricating system
187
3.9.1 Crankcase breather system rubber hoses (SL 219)
187
3.9.2 Oil centrifuge removal and installation (depending on application)
189
3.9.3 Spin-on oil filters removal and installation
192
3.9.4 Prelubricating pump removal and installation (depending on application)
193
3.10 Cooling system
197
3.10.1 Venting line removal and installation
197
3.10.2 Turbocharger cooling lines removal and installation
203
3.10.3 Thermostat HT and housing removal and installation (SL 217)
215
3.10.4 Thermostat LT and housing removal and installation (SL 217)
217
3.10.5 Coolant pump HT removal and installation (SL 216)
220
3.10.6 Coolant pump LT removal and installation (SL 215)
222
3.10.7 Fan drive (option)
225
KD62V12 33525088601_7_1 EN_US
2021-07
