Exhaust aftertreatment system
Fig. 278: Removing injector nuts
u Remove the injector fixing nuts 9, and washers 8.
Fig. 279: Removing injector assembly
u Remove the injector 3, and the retaining plate 10 together as an assembly.
Information
Make sure the screws remain in place on the reactor.
246
© 2021 by Kohler Co. All rights reserved.
KD62V12 33525088601_7_1 EN_US
2021-07
