TP-6903 5/16a Diagnostic Troubleshooting Codes 35
P-Code SPN FMI Description Possible Cause Corrective Action
P1690 911 31 Maintenance Reminder
 Not applicable  Not applicable
P2096 3227 18 Post Catalyst Fuel Trim
System Too Lean
 Not applicable  Not applicable
P2097 3227 16 Post Catalyst Fuel Trim
System Too Rich
 Not applicable  Not applicable
P2100 3464 5 Throttle Actuator Control
Motor Circuit Open
 Open circuit in
throttle control motor.
 Bad throttle body.
 Check the throttle motor and
leads. Refer to Section 4.11.
 Replace the throttle body. Refer
to Section 5.1.
P2102 3464 4 Throttle Actuator Control
Motor Circuit Low
 Short circuit across
throttle control motor
or ground.
 Bad throttle body.
 Check the throttle motor leads.
Refer to Section 4.11.
 Replace the throttle body if the
code continues to occur. Refer to
Section 5.1.
P2103 3464 3 Throttle Actuator Control
Motor Circuit High
 Short circuit across
throttle control motor
or power.
 Bad throttle body.
 Check the throttle motor leads.
Refer to Section 4.11.
 Check for smooth throttle
operation.
 Replace the throttle body if the
code continues to occur. Refer to
Section 5.1.
P2109 3464 13 Throttle Position Sensor
A Minimum Stop
Performance
 Problem with throttle
body or leads.
 Check for smooth throttle
operation.
 Troubleshoot the TP sensor
leads. Refer to Section 4.11.
 Perform manual throttle zero
process using the scan tool.
 Replace the throttle body if the
code continues to occur. Refer to
Section 5.1.
P2111 3464 7 Throttle Actuator Control
System - Stuck Open
 Throttle jammed
open.
 Possible problem
with the throttle gear
box.
 Check for smooth throttle
operation.
 Check the throttle for ice or
blockage.
 Troubleshoot the TP sensor
leads. Refer to Section 4.11.
 Replace the throttle body. Refer
to Section 5.1.
 If the throttle returns to the default
position (fast idle) while
disconnected from the ECM, then
replace the ECM. Refer to
Section 5.4.
P2112 3464 7 Throttle Actuator Control
System - Stuck Closed
 Throttle jammed
closed.
 Possible problem
with the throttle gear
box.
 Check for smooth throttle
operation.
 Check the throttle for ice or
blockage.
 Troubleshoot the TP sensor
leads. Refer to Section 4.11.
 Replace the throttle body. Refer
to Section 5.1.
 If the throttle returns to the default
position (fast idle) while
disconnected from the ECM, then
replace the ECM. Refer to
Section 5.4.
