Kohler KG2204T

36 Diagnostic Troubleshooting Codes TP-6903 5/16a
P-Code SPN FMI Description Possible Cause Corrective Action
P2113 3464 13 Throttle Position Sensor
B Minimum Stop
Performance
 Problem with throttle
body or leads.
 Check for smooth throttle
operation.
 Troubleshoot the TP sensor
leads. Refer to Section 4.11.
 Perform manual throttle zero
process using the scan tool.
 Replace the throttle body if the
code continues to occur. Refer to
Section 5.1.
P2119 3464 14 Throttle Actuator Control
Throttle Body
Range/Performance
 Throttle position or
signal is incorrect.
 Check for smooth throttle
operation.
 Troubleshoot the TP sensor
leads. Refer to Section 4.11.
 Perform manual throttle zero
process using the scan tool.
 Replace the throttle body. Refer
to Section 5.1.
P2122 91 4 Throttle/Pedal Position
Sensor/Switch D Circuit
Low Input
 Not applicable  Not applicable
P2123 91 3 Throttle/Pedal Position
Sensor/Switch D Circuit
High Input
 Not applicable  Not applicable
P2127 2972 4 Throttle/Pedal Position
Sensor/Switch E Circuit
Low Input
 Not applicable  Not applicable
P2128 2972 3 Throttle/Pedal Position
Sensor/Switch E Circuit
High Input
 Not applicable  Not applicable
P2132 2973 4 Throttle/Pedal Position
Sensor/Switch F Circuit
Low Input
 Not applicable  Not applicable
P2133 2973 3 Throttle/Pedal Position
Sensor/Switch F Circuit
High Input
 Not applicable  Not applicable
P2135 51 7 Throttle/Pedal Position
Sensor/Switch A/B
Voltage Correlation
 Throttle position
sensors do not
match.
 Check TP sensor voltage while
manually changing the throttle
position.
 Troubleshoot the TP sensor
leads. Refer to Section 4.11.
 Replace the throttle body. Refer
to Section 5.1.
P2138 91 7 Throttle/Pedal Position
Sensor/Switch D/E
Voltage Correlation
 Not applicable  Not applicable
P2139 91 7 Throttle/Pedal Position
Sensor/Switch D/F
Voltage Correlation
 Not applicable  Not applicable
P2140 91 7 Throttle/Pedal Position
Sensor/Switch E/F
Voltage Correlation
 Not applicable  Not applicable
