8
Specifi cations
KohlerEngines.com 22 690 01 Rev. --
Engine Dimensions-Oil Filter Side
F
E
G
H
I
K
A
B
D
C
J
L
M
N
O
P
Q
R
S
T
A 317.1 mm (12.49 in.) B 45.2 mm (1.78 in.) C 34.3 mm (1.35 in.) D
75.5° Speed Control
Lever Travel
E Optional Fuel Pump F Throttle Cable Clip G
324.9 mm
(12.79 in.)
H
226.7 mm (8.93 in.)
Lifting Point
I 215.7 mm (8.49 in.) J
14.5 mm (0.57 in.) Oil
Filter Removal
K
113.6 mm (4.47 in.) to
Oil Filter
L Oil Filter
M
Engine Mounting
Surface
N
Oil Drain Plug 3/8
N.P.T. IN.
O
6.5° Choke Lever
Travel
P 17.0 mm (0.67 in.)
Q
39.4 mm (1.55 in.) to
Optional
Carburetor
Shutdown
Solenoid
R
127.1 mm (5.01 in.)
Connection for
Evaporative Hose
S Air Filter and Cover T
33.8 mm (1.33 in.) Air
Cleaner Cover
Removal
