Kohler KS595 Service Manual

46
Electrical System
KohlerEngines.com 22 690 01 Rev. --
Wiring Diagram-12/15 Amp Regulated Battery Charging System with Fuel Relay and Stator Brake Relay
_
+
H
R
S
J
M
O
K
D
E
T
N
T
D
F
I
J
S
O
P
B
AC
AC
B+
X
U
G
A
B
L
C
A
AA
Y
A
W
V
Z
Z
P
A Red B Green C Violet D White
E Spark Plug F Fuel Shut-off Solenoid G
Optional Oil Sentry
™
Switch (Indicator)
H Bendix Starter
I Engine Connector J Starter Solenoid K Ground-To-Kill Lead L Key Switch
M Optional Oil Sentry
™
N Optional Fuse O Battery P Rectifi er-Regulator
Q Flywheel R Stator S Ignition Module T Accessory
U Fuel Shut-off Relay V Orange W Yellow X
Equipment Safety
Circuit
Y Stator Brake Relay Z Brown AA Stator Connector
