64
5. Apply the gasket provided to the top of the lower ice machine frame as shown. Place the
gasket over the frame spacers to secure them in position.
6. Position the stacking chute in the lower machine as shown. Locate on the support
channels, against the partition wall.
7. Carefully lift the upper machine and place it on top of the lower machine and align the
frames. Fasten the frames together using the screws, washers and lock nuts provided
DANGER: It is highly recommended that 2 or more people perform this job, if the
machine falls it could cause serious injury or death.
