6 Modes and Operating Conditions
6.1 Terms and Definitions
 TA: Temperature of indoor ambient.
 TE: Temperature of evaporator.
 TS: The set temperature.
 DAHT: Heater sensor.
6.2 Protection Functions
 The compressor restart protection has a delay of 3 minutes.
 5 minute operation for compressor in cooling mode.
 Sensor protection against an open or short circuit.
6.3 Auto Mode
 AUTO Mode is a setting that allows the unit to automatically switch between COOL, FAN and HEAT
in order to achieve and maintain the desired set temperature.
 In Auto mode the unit will choose cooling, heating or fan-only mode based on ΔT(ΔT=TA-TS)
ΔT = TA - TS
Running mode
ΔT ＞ 4F
Cooling
-2F ≤ ΔT ≤ 4F
Fan-only
ΔT < -2F
Heating (Setting temperature is TS-1F)
 The unit will default to running mode when in auto mode under the following circumstances:
 Powering on, changing mode to auto mode or adjusting temperature in auto mode will cause the
unit to default to running mode again.
 A: In auto mode, if the compressor does not run for 15 minutes check condition B.
 B: If ΔT<-8℉ or ΔT ＞2℉, the unit will default to running mode again according to ΔT until the
compressor stops.
