Kollmorgen AKM11B User Manual

Connections and cables
Data AKM3
Power connection 4 + 4 poles, round, angular
Motorcable, shielded 4 x 1
Motor cable with control leads, shielded 4x1+2x0,75
Resolver connection 12 poles, round, angular
Resolver cable, shielded 4x2x0,25mm²
Encoder connection (option) 17 poles, round, angular
Encoder cable, shielded 7x2x0,25mm²
Dimensions (drawing in principle)
Radial-/axial forces at the shaft end
- A.4.043.4/02, 13 - A.4.043.3/02, 044.3/05, 09, 10
Servomotors AKM 29
Kollmorgen 05/2006 Technical Data

Kollmorgen AKM11B Specifications

General

Brand	Kollmorgen
Model	AKM11B
Category	Servo Drives
Language	English
