Kollmorgen AKM11B User Manual

4 Appendix
4.1 Assignment of RediMount gearhead mounts
Motor RediMount Flange length [mm] Motor RediMount Flange length [mm]
AKM1xx-A RM060-130 35,1
AKM4xx-C
RM075-124 42,9
AKM1xx-C RM060-XXX in preparation RM090-124 44,1
AKM2xx-A
RM060-6 31,0 RM100-124 43,7
RM075-6 in preparation RM115-124 48,9
RM090-6 62,7
AKM5xx-A
RM090-71 62,7
RM100-6 in preparation RM100-71 43,7
AKM2xx-C
RM060-17 31,0 RM115-71 48,9
RM075-17 42,9 RM142-71 69,6
RM090-17 44,1 RM180-71 91,4
RM100-17 62,7
AKM5xx-C
RM090-53 in preparation
RM115-17 48,9 RM100-53 in preparation
AKM3xx-A
RM060-19 31,0 RM115-53 59,9
RM075-19 42,9 RM142-53 in preparation
RM090-19 44,1 RM180-53 in preparation
RM100-19 58,9
AKM6xx-A
RM115-92 in preparation
AKM3xx-C
RM060-XXX in preparation RM142-92 81,5
RM075-XXX in preparation RM180-92 91,4
RM090-XXX in preparation RM220-92 69,5
RM100-XXX in preparation
AKM7xx-A
RM142-114S 85,3
AKM4xx-A
RM075-40 42,9 RM180-114 91,4
RM090-40 44,1 RM220-114 69,6
RM100-40 43,7
RM115-40 48,9
These gearheads can be fitted to RediMount:
RM060: DT60, DTR60, DTRS60, DTRH60, NT23, NTP23, NT60, NTR23, UT006,
UTR006, EQ23, EQ60
RM075: UT075, UTR075, UT090, UTR090
RM090: DT90, DTR90, DTRS90, DTRD90, DTRH90, NT34, NTP34, NT90, NTR34
RM100: UT010, UTR010, ET010, UT115, UTR115
RM115: DT115, DTR115, DTRS115, DTRD115, DTRH115, NT42, NTP42, NT115,
NTR42
RM142: DT142, DTR142, DTRS142, DTRD142, DTRH142, NT142, UT014, UTR014,
ET014
RM180: UT018, UTR018, ET018
RM220: UT220
You can find further information on Redimount and gearheads on our website.
38 Servomotors AKM
Appendix 05/2006 Kollmorgen
