2.2 Assembly / Wiring
Only qualified staff with knowledge of mechanical engineering are permitted to assemble
the motor.
Only staff qualified and trained in electrical engineering are allowed to wire up the motor.
The procedure is described as an example. A different method may be appropriate or necessary,
depending on the application of the equipment.
Warning!
Protect the motor from unacceptable stresses.
Take care, especially during transport and handling, that components are not bent and that
insulation clearances are not altered.
Always make sure that the motors are de-energized during assembly and wiring, i.e. No vol
-
tage may be switched on for any piece of equipment which is to be connected.
Ensure that the switch cabinet remains turned off (barrier, warning signs etc.).
The individual voltages will only be turned on again during setup.
Note!
The ground symbol
X, which you will find in the wiring diagrams, indicates that you
must provide an electrical connection, with as large a surface area as possible, between the
unit indicated and the mounting plate in the switch cabinet. This connection is to suppress
HF interference and must not be confused with the PE (protective earth) symbol (protective
measure to EN 60204).
To wire up the motor, use the wiring diagrams in the Installation and Setup Instructions of
the servo amplifier which is used.
14 Servomotors AKM
Installation / Setup 05/2006 Kollmorgen
