EQUIPPING FIRE EXTINGUISHER AND FIRST-AID KIT ATTACHMENTS, OPTIONS
6-10
EQUIPPING FIRE EXTINGUISHER AND FIRST-AID KIT 6
Equipping the fire extinguisher and the first-aid kit at the illustrated position needs brackets (if equipped).
The fire extinguisher and the first-aid kit can be installed to the positions shown in the following illustration.
Equipping the fire extinguisher and the first-aid kit at the illustrated position needs brackets (option). For the brack-
ets, please contact your Komatsu distributor.
When installing a fire extinguisher, install it in the position shown in the diagram.
q Machine equipped with cab
q Machine equipped with canopy
When installing a first aid box, install it in the position shown in
the diagram.
