Komatsu D37EX-21 - General View; General View of Machine

GENERAL VIEW OPERATION
3-2
GENERAL VIEW 3
GENERAL VIEW OF MACHINE 3
Machine equipped with canopy
Machine equipped with cab
(1) Blade (7) Track frame
(2) Angle cylinder (8) Lift cylinder
(3) Radiator mask (9) Idler
(4) Canopy (10) Frame
(5) Track shoe (11) Cab
(6) Sprocket
